MEMS Inertial Measurement Unit (MEMS IMU)

MS4000 Series

Product Overview

The MU4000 series is a highly reliable, cost-effective six-axis MEMS inertial measurement unit (IMU), suitable for applications like inertial navigation and attitude stabilization. It supports customized hardware/software configurations and the development of high-precision MEMS gyroscopes.


Core Process Technology

It integrates high-performance MEMS gyroscopes (for angular motion measurement) and accelerometers (for linear motion measurement) in an independent structure—both represent leading MEMS inertial device technology. Full-temperature parameter compensation (zero offset, scale factor, etc.) ensures long-term measurement accuracy; combined with overall vibration-damping and sealed design, it can accurately measure the carrier’s angular and linear motion parameters even in harsh environments, delivering a low-cost, high-reliability solution.


Device & Calibration Compensation Technology

Leveraging accumulated core technologies, it adopts high-speed sampling, full-temperature static error compensation (zero offset, installation error, etc.), and dynamic error compensation (coning error) to ensure high product performance.

Key Features

  1. Full-temperature compensation (full-temperature calibration from -45℃ to +80℃)
  2. 100% localized production (domestic)
  3. High performance, small size, light weight, low power consumption
  4. 1KHz high-speed sampling
  5. Resistant to harsh mechanical environments
  6. Supports over-the-air software upgrade

Main Applications

  1. Attitude reference system
  2. Guidance control system
  3. Vessel/vehicle attitude measurement
  4. Inertial/satellite integrated navigation system
  5. Drilling and mining system
  6. Mobile surveying and mapping system
  7. Mobile satellite communication (SATCOM)
  8. Autonomous driving vehicle
  9. Seeker stabilization
Performance Specifications
MEMS Gyroscope
Model MU4001 MU4002 MU4003
Range (°/s) 500 500 500
Bias (°/h) 10 3 1
Bias Stability (°/h, 10s smoothed) 3 0.8 0.3
Bias Repeatability (°/h) 3 0.8 0.3
Scale Factor Nonlinearity (ppm) 100 100 50
Bandwidth (Hz) 100 80 80
MEMS Accelerometer
Range (g) 40
Bias (μg) 1000
Bias Stability (μg) 80
Bias Repeatability (μg) 100
Scale Factor Nonlinearity (ppm) 300
Bandwidth (Hz) 100
Electrical & Mechanical
Power Supply (V) 5±0.2
Power Consumption (W) <1
Start-up Time (s) 2
Communication Interface RS-422
Update Rate (Hz) 200 (customizable, max 1000)
Dimensions (mm×mm×mm) 44.8×38.6×21.5
Weight (g) 60
Environmental Adaptability
Operating Temperature (°C) -45 ~ 80
Storage Temperature (°C) -55 ~ 85
Vibration (g, Rms) 7.72
Shock (g) 1000g/1ms (with cable)
Reliability
MTBF (h) 20000
